| Nr. | Menge | Artikel | ||
|---|---|---|---|---|
| 1 |
Platten-kit (598684111) SIDE DISCHARGE PLATE | |||
| 1 |
Klappe (598684119) REAR DOOR | |||
| 1 | Dichtungsscheibe (598684128) | |||
| 1 | Rahmen (598861201) | |||
| 1 |
Abdeckungssatz (598684122) FRONT COVER | |||
| 1 |
Achse (529595301) For 970488402, 970488404. WHEEL AXLE | |||
| 1 |
Achse (598818701) For 970488401, 970488403. WHEEL AXLE | |||
| 2 |
Laufrad (598512901) FRONT WHEEL, kit contains 2 wheels | |||
| 2 |
Zahnrad (529596401) For 970488402, 970488404. WHEEL DRIVE | |||
| 2 |
Zahnrad (598684117) For 970488401, 970488403. WHEEL DRIVE | |||
| 1 |
Getriebesatz (598513701) REAR TRANSMISSION | |||
| 1 |
Achse (598684109) For 970488401,970488403. WHEEL AXLE | |||
| 1 |
Achse (529595501) For 970488402, 970488404. WHEEL AXLE | |||
| 2 |
Laufrad (529595601) For 970488402, 970488404. REAR WHEEL, kit contains 2 wheels | |||
| 2 |
Laufrad (598684103) For 970488401,970488403. REAR WHEEL, kit contains 2 wheels | |||
| 1 |
Platte (598860801) GAUGE PLATE | |||
| 1 |
Bolzen (598861301) BOLT CLIP | |||
| 1 |
Abdeckung (598819001) SIDE PROTECTION COVER | |||
| 1 |
Griff Kpl. (529595701) For 970488402, 970488404. HEIGHT ADJUSTMENT HANDLE | |||
| 1 |
Griff Kpl. (599139101) For 970488401, 970488403. HEIGHT ADJUSTMENT HANDLE | |||
| 1 |
Platten-kit (599139001) For 970488401, 970488403. HEIGHT ADJUSTMENT PLATE | |||
| 1 |
Platten-kit (529595801) For 970488402, 970488404. HEIGHT ADJUSTMENT PLATE | |||
| 1 |
Stange (529596201) For 970488402, 970488404. HEIGHT ADJUSTMENT ROD | |||
| 1 |
Stange (599138801) For 970488401, 970488403. HEIGHT ADJUSTMENT ROD | |||
| 1 |
Feder (599138901) HEIGHT ADJUSTMENT SPRING | |||
| 2 | Radabdeckung (587585101) | |||
| 2 | Radabdeckung (587585301) | |||
| 4 | Verschlussbolzen (587913501) | |||
| 8 | Lager (587912901) | |||
| 2 | Scheibe (587914601) | |||
| 2 | Radabdeckung (587585001) | |||
| 2 | Radabdeckung (587585201) | |||
| 2 | Laufrad (587585401) |
| Nr. | Menge | Artikel | ||
|---|---|---|---|---|
| 1 |
Grassfangsack Kpl (598684121) KIT |
| Nr. | Menge | Artikel | ||
|---|---|---|---|---|
| 1 | Regulierhebel Kpl. (598818201) | |||
| 1 | Stange (598861901) | |||
| 1 |
Griff Kpl. (598722001) HANDLE AND SHEATH | |||
| 1 | Regulierhebel Kpl. (598684129) | |||
| 1 | Griff Kpl. (598825601) | |||
| 1 |
Kabel (529596301) FLAMEOUT CABLE | |||
| 1 |
Kabel Kpl. (598861601) DRIVE CABLE ASSY | |||
| 1 |
Klammer (598861401) CABLE CLIP | |||
| 2 |
Knopf Kpl. (598684125) For 970488401, 970488403. KNOB | |||
| 2 |
Knopf Kpl. (529596001) For 970488402, 970488404. KNOB | |||
| 1 |
Support Kit (598684113) HANDLE BRACKET |
| Nr. | Menge | Artikel | ||
|---|---|---|---|---|
| 1 |
Motor (599912501) For 970488401 Up to S/N 20230100001, 970488402 EU/LATAM Up to S/N 20232000117 | |||
| 1 |
Motor (599912504) For 970488401 from S/N 20230100001, 970488402 EU/LATAM from S/N 20232000117 | |||
| 1 | MOTOR (599912503) For 970488404 BR/PY | |||
| 1 | MOTOR (599912505) For 970488403 from S/N 20254600001. CDA/PARTS ONLY SEE HS166A ENGINE IPL | |||
| 1 |
Motor (599912301) For 970488401 AUSTRALIA | |||
| 1 |
Motor (599912502) For 970488403 up to NS/N 20221000660. CDA/PARTS ONLY SEE HS166A ENGINE IPL | |||
| 1 |
Höheneinstellung (529595901) For 970488402, 970488404 | |||
| 1 | HÖHENEINSTELLUNG (598684107) For 970488401, 970488403 | |||
| 1 |
Installationskit (529595101) BOLTS AND NUTS | |||
| 1 |
Riemenscheibe (529596102) For 970488401 from S/N 20230100001, 970488402 EU/LATAM from S/N 20232000117, 970488404 from S/N 20225100001 | |||
| 1 |
Riemenscheibe (529596101) For 970488401 AUSTRALIA, 970488401 EU/LATAM up to S/N 20230100001 and 970488402 up to S/N 20232000117, All 970488403 | |||
| 1 |
Abdeckung (598513501) BELT COVER | |||
| 1 |
Messeraufnahme (529595001) For 970488401 AUSTRALIA, 970488401 EU/LATAM up to S/N 20230100001 and 970488402 up to S/N 20232000117, 970488403 up to S/N 20221000660 | |||
| 1 |
Messeraufnahme (529595002) For 970488401 from S/N 20230100001, 970488402 EU/LATAM from S/N 20232000117, 970488403 from S/N 20254600001, 970488404 from S/N 20225100001 | |||
| 1 | Riemen (598974001) | |||
| 1 |
Klinge (598562601) Collect blade | |||
| 0 |
Husqvarna Mulchkit Lc 153p/153s/151/151s (598018001) Accessory, Standard for 970488403 | |||
| 0 |
Klinge (597683901) Mulch blade |
