| Nr. | Menge | Artikel | ||
|---|---|---|---|---|
| 1 |
Antriebskabel (589818808) Includes Cable | |||
| 1 | O-ring (532197480) | |||
| 1 | Scheibe (532088348) | |||
| 1 |
Rückplatte (536153801) For 96141021200 | |||
| 1 |
Riemen (580364604) For 96141029100, 96141029101 | |||
| 1 |
Riemen (580364604) For 96141021200 | |||
| 1 |
Riemen (580364604) For all EXCEPT 96141029100, 96141029101, 96141021200 | |||
| 1 | GETRIEBE (581975503) For 96141029102 | |||
| 1 |
Getriebe (581680801) For all EXCEPT 96141029102 | |||
| 1 |
Riemenscheibe (586963002) For all EXCEPT 96141029100, 96141029101, 96141029102 | |||
| 1 |
Riemenscheibe (532194128) For 96141029100, 96141029101, 96141029102 | |||
| 1 |
Einstellvorrichtung (581497908) RH | |||
| 1 |
Einstellvorrichtung (581497907) LH | |||
| 1 | Knopf (532701037) | |||
| 1 | Riemenabdeckung (580806901) | |||
| 1 | Bolzen (817000510) | |||
| 1 | HALTER (581313802) | |||
| 1 | BEFESTIGUNG (532426066) For all EXCEPT 96141021200 | |||
| 1 | HALTER (589318302) For 96141021200 | |||
| 1 | Scheibe (532067725) | |||
| 1 | Federring (812000058) | |||
| 1 | Staubschutz (581840401) | |||
| 1 |  | Mutter (532191730) | ||
| 1 | Sperrklinke (532404845) | |||
| 1 | Laufrad (581685101) | |||
| 1 |  | Mutter (532409149) | ||
| 1 | Treibrad (532404835) | |||
| 1 | EINSTELLVORRICHTUNG (532431138) For 96141021200, RH | |||
| 1 | EINSTELLVORRICHTUNG (532437872) For all EXCEPT 96141021200, RH | |||
| 1 | EINSTELLVORRICHTUNG (532437871) For all EXCEPT 96141021200, LH | |||
| 1 | EINSTELLVORRICHTUNG (532431139) For 96141021200, LH | |||
| 1 | Screw (532163409) | |||
| 1 | Rad Kpl. (532401273) | |||
| 1 | Satz (532438489) | |||
| 1 | Satz (532438489) | |||
| 1 | SICHERUNGSSCHEIBE (532415585) | |||
| 1 | SICHERUNGSMUTTER (532415586) | |||
| 1 | TASCHE (532423849) For 96141029102 | |||
| 1 |  | Feder (581351301) | ||
| 1 | HALTER (532442113) | |||
| 1 | Screw (532181698) | |||
| 1 | Riemenscheibe (587969201) | |||
| 1 | Schraube (581127601) |
| Nr. | Menge | Artikel | ||
|---|---|---|---|---|
| 1 | EINSTELLHEBEL (585854806) | |||
| 1 |
Kabel (596288401) For 96141021200 | |||
| 1 |
Kabel (532424983) For 96141029103, 96141029104, 96141029105 | |||
| 1 |
Kabel (532427497) For 96141029100, 96141029101, 96141029102 | |||
| 1 |
Halter (532430034) For 96141029100, 96141029101, 96141029102 | |||
| 1 |
Tie Wrap (532007192) For 96141029100, 96141029101, 96141029102 | |||
| 1 | Knopf (532182398) | |||
| 1 |
Screw (532178848) For 96141029100, 96141029101, 96141029102 | |||
| 1 |
Regulierung (580849102) For 96141029100, 96141029101, 96141029102 | |||
| 1 |
Regulierhebel Kpl. (587689302) For all EXCEPT 96141029100, 96141029101, 96141029102 | |||
| 1 | Tuerregal (593304501) | |||
| 1 | Keil (532425575) | |||
| 1 | Knopf (532185577) | |||
| 1 |
Stopfen (532437516) For all EXCEPT 96141021200 | |||
| 1 | Platte (581782101) | |||
| 1 | Knopf (581912601) | |||
| 1 | FÜHRUNG (581902101) | |||
| 1 |
Feder (532419949) LH | |||
| 1 | Screw (532141841) | |||
| 1 |
Feder (532419948) RH | |||
| 1 | Screw (532419945) | |||
| 1 |
Bolzen (586212501) For all EXCEPT 96141029100 | |||
| 1 |  |
Bolzen (596136401) For 96141029100 | ||
| 1 | Grassfangsack Kpl (580943401) | |||
| 1 | Rahmen (585054702) | |||
| 1 | SPERRHAKEN (532441192) For all EXCEPT 96141021200 | |||
| 1 |
Tür (594942002) For all EXCEPT 96141021200 | |||
| 1 | TUERREGAL (593241102) For 96141021200 | |||
| 1 | Halter (532438134) | |||
| 1 | SCHARNIER (532175735) For all EXCEPT 96141021200 | |||
| 1 |
Bolzen (817000510) For all EXCEPT 96141029100, 96141029101, 96141029102 | |||
| 1 | Deflektor (532426129) | |||
| 1 |
Halter (585900703) LH | |||
| 1 | HALTER (585900803) RH | |||
| 1 |  | Bolzen (532150406) | ||
| 1 |
Scharnier (532193000) For all EXCEPT 96141021200 | |||
| 1 |
Sicherungsmutter (596041001) For all EXCEPT 96141021200 | |||
| 1 | GEHÄUSE KPL (581708359) For 96141029102 | |||
| 1 | GEHÄUSE KPL (581708327) For all EXCEPT 96141029102 | |||
| 1 |
Stange (532175650) For all EXCEPT 96141021200 | |||
| 1 |
Adapter (581851501) For 961410291 | |||
| 1 |
Adapter (591344701) For 96141021200 | |||
| 1 |
Klinge (532406713) For 96141021200 | |||
| 1 |
Klinge (580244002) For 961410291 | |||
| 1 | Scheibe (532851074) | |||
| 1 |  | Scheibe (596238701) | ||
| 1 | Screw (532851084) | |||
| 1 | PLATTE (581238901) For 96141029100, 96141029101, 96141029102 | |||
| 1 | PLATTE (532430599) For all EXCEPT 96141029100, 96141029101, 96141029102 | |||
| 1 | Aufkleber (581724301) | |||
| 1 |
Bolzen (817000510) For all EXCEPT 96141029100, 96141029101, 96141029102 | |||
| 1 |
Screw (532437345) For 96141029100 | |||
| 1 |
Schraube (584299401) For 96141029101, For 96141029100 | |||
| 1 | Screw (817411312) | |||
| 1 | Mutter (532155377) | |||
| 1 |
Lenkung Kpl. (593270403) For all EXCEPT 96141029100, 96141029101, INCLUDES PLUG | |||
| 1 | EINSTELLHEBEL (532441197) For 96141029100, 96141029101 | |||
| 1 | Schraube (532191574) | |||
| 1 | Klammer (532428124) | |||
| 1 | Klammer (532197991) | |||
| 1 | HALTER (581115302) | |||
| 1 | TASCHE (532423849) For all EXCEPT 96141029100, 96141029101, BAG OF PARTS ( INCLUDES KEY NUMBERS12 & 59 | |||
| 1 | ABDECKUNG VORNE KPL (585668702) For all EXCEPT 96141029100, 96141029101, 96141029102 | |||
| 1 | ABDECKUNG (532437389) For 96141029100, 96141029101, 96141029102 | |||
| 1 |
Deckel (580290001) For all EXCEPT 96141021200 | |||
| 1 |
Schraube (580768701) For all EXCEPT 96141021200 | |||
| 1 |
Schraube (584299401) For 96141029101 |
